ShareSolder Masks, Inks & Liquid Coverlays for PCB Fabrication
Technic is a global supplier of solder masks, legend inks and liquid coverlay materials to the Printed Circuit Board industry. We offer liquid photoimageable solder masks and coverlays, as well as UV and thermal curable solder masks, curable marking inks and etching resist.
Liquid Photoimageable Coverlay & Solder Mask
Black Liquid Soldermask for
Flexible Fine Pitch Direct Imaging
- Ideal for demanding assembly conditions
- No cracking – durable and flexible
- Less than 10 microns of undercut
- High resolution
- Excellent chemical resistance
TechniFlex LCL 1000F/423M is ideally suited for demanding assembly conditions, including hot-bar soldering or multiple lead-free reflows. Extensive testing of TechniFlex 423M has shown no cracking after multiple 180 degree bends, even when processing 12-micron polyimide substrate.
TechniFlex LCL 1000F/423M provides exceptionally fine resolution in a matte black product. With less than 10 microns of undercut, TechiFlex LCL1000F/423M consistently provides high resolution on 50-micron solder dams with excellent chemical resistance to ENIG, ENEPIG, Ag and Sn finishes.
TechniFlex LCL 1000F/423M is available in two versions:
- TechniFlex LCL 1000F/423M U6 - for direct imaging/manual exposure
- TechniFlex LCL 1000F/423M U7 - for either direct imaging/manual exposure or roll to roll coating operations
TechniFlex LCL 1000F
Liquid photoimageable solder mask/coverlay for Rigid-Flexible circuit panels
- Easily passes industry flexibility testing (10,000x at 180° bending with 1/16 inch mandrel)
- Halogen free and RoHS compliant
- 2 mil resolution capability for today's most advanced technologies
- Excellent Copper, FR4 and Polyimide adhesion
- Passes UL94 V-0 & NASA outgassing specifications
- Meets or exceeds IPC SM 840C, Bellcore TR-NWT-000078, and MIL P55110D specifications
- Colors - Green, Amber, (Other colors are available upon request)
TechniMask ISR 1000E
Liquid photoimageable solder mask for rigid circuit panels
- Excellent cosmetic appearance, with a range of colors and surface finishes
- Wide process latitude enabling fine image reproduction with clean PTH/via development
- Resolution capability below 2 mils for ultra fine pitch solder dams
- Superior resistance to all plated surface finishing processes including ENIG, immersion tin and immersion silver
- UL File #E83246, rated 94 V-0 with soldering limits of 20 seconds @ 288°C
- Meets or exceeds IPC SM 840C, Bellcore TR-NWT-000078, and MIL P55110D specifications
- Colors – Green, Blue, White, Red, Black, Clear
UV and Thermal Cure SolderMasks
TechniMask UV-SR2
UV curable Rigid/Flexible solder mask
- Suitable for use on single, double sided, PTH, multilayer PC boards and flexible circuit boards
- No bleed around exposed pads
- Superior resistance to all plated surface finishing processes
- UL File #E83246, rated 94V.0 with soldering limits of 20 seconds @ 260°C
- Meets or exceeds IPC SM-840C, Bellcore TR-NWT-000078, and Mil P55110D specifications
- Colors – Green, Blue, White, Red, Black, Yellow, Clear
UV and Thermal Curable Marking Inks
Protokote SPN
Solvent free single pack thermal cure marking inks
- No VOCs (volatile organic compounds), single component, ready to use
- No mesh drying, no discoloration after curing
- Excellent adhesion to a wide variety of laminates and solder resists
- High definition
- Colors - White, Yellow, Black
UV and Thermal Etching Resist
Protokote 112
Thermal cure etching/plating resists
- Alkaline strippable/ 3-7%NaOH at 40-50°C
- High definition/minimizing resist smearing
- Chemically resistant to all acid plating processes
- Resistant to acid etching processes
- Color - Translucent Blue
